Rexroth A10VSO100 Variable Pressure Piston Pump for Industrial Use

A10VSO100DFLR/31R-PPA12K37 A10VSO100DFLR/31R-VKC62K01 A10VSO100DFLR/31R-VKC62K68
A10VSO100DFLR/31R-VPA12N00 A10VSO100DFR1/31L-PKC62N00 German Rexroth Variable Pressure Piston Pump Mining Loader

FAQ:

1. Scope

This FAD outlines the functional specifications, performance parameters, and quality requirements for the A10VSO100 series axial piston pumps, including:

• Model Variants: A10VSO100DR/DFR/EP

• Applications: Industrial hydraulics, mobile machinery, and power units.

------

2. Key Specifications

Parameter    Value/Range    Remarks
Displacement    100 cm³/rev    Fixed displacement design
Max Pressure    350 bar (continuous)    Peak: 400 bar
Speed Range    800–3600 rpm    Dependent on lubrication conditions
Fluid Compatibility    Mineral oil (ISO VG 46-68)    Temp range: -20°C to +80°C
Efficiency    ≥92% (volumetric)    Tested per ISO 4409

------

3. Functional Components

• Housing: Aluminum alloy (hardness: HB 90–120).

• Rotating Group: Ceramic-coated pistons for reduced wear.

• Control Mechanism: Pressure compensator (DFR) or load-sensing (EP) options.

• Seals: NBR/FKM materials (valid date: 10 years from manufacture).

------

4. Quality & Testing

• Inspection Criteria:

  ◦ IQC: Dimensional checks per DWG-100-01 (tolerance ±0.05mm).

  ◦ IPQC: Leakage test at 1.5x rated pressure (15-min hold).

  ◦ OQC: Noise level ≤75 dB(A) at 1500 rpm.

• Defect Classification:

  ◦ Critical (CR): Seal failure, pressure drop >10%.

  ◦ Major (MA): Surface finish non-conformity.

------

5. Compliance & Standards

• ISO 4409: Hydraulic pump performance testing.

Rexroth A10VSO100 piston pump

variable pressure industrial pump

hydraulic piston pump with warranty

Rexroth A10VSO100 Variable Pressure Piston Pump for Industrial Use Images
